- Place of Origin: Zhejiang, China
- Brand Name: TiHi
- Model Number: W309
- :
- :
- :
- :
- :
- :
- :
- :
- :
- :
Product Description
Product Application
Suitable for welding in steel, stainless steel, zinc, brass, aluminum materials, and widely apply in the industry of sanitary,electronic component, motor fitting(sensor, tappet , nozzle, filter,valve) and Lithium battery.Welding pattern: dot, line, square or any patterns designed by AUTOCAD
Technical Parameter of W309 | |
Model No.: | W309 |
Laser Power: | 200W 500W 800W |
Laser Wavelength: | 1064nm |
Beam Range: | 0.3-3mm |
Pulse Width: | 0.1-20ms |
Pulse Frequency: | 1-100HZ |
Position System: | Red point/CCD |
Working table CNC system: | PLC/PC |
Working table scale: | 200*200mm--300mm*600mm(Optional) |
Position Precision: | 0.05mm |
Repeated Location Accuracy: | ±0.02mm |
Cooling: | Water Cooling |
Working table Bearing Weight: | 50Kgs |
Power Comsuption: | 4KW 8KW 12KW |
Net Weight: | 300Kgs |
Size Measurement: | 135*70*160cm |
Working Temperature: | 10℃-35℃ |
Main Features
Automatic laser welding machine has a integrating and compacted design, and contains many advantages such as a high power output, stable energy,good quality beams, easy operated and widely applications.
Ceramic converging cavity is imported from The Britain, it is corrosion and high temperature resistant,with a high service life,the life of xenon lamp is more than 8million times.
About Us
ZheJiang TiHi Laser Equipment Co.,ltd is a hightech enterprise which devoted to the researching,producing and selling laser equipments. And our technique team is under the leading of two Doctors who are well -experienced in fiber laser field, and a strong sales team is always ready to provide the most comprehensive pre-sales support and service. Our products mainly include fiber laser marking machine, laser cutting machine and laser welding machine, which are highly used in the scope of industry of hardware, motor fittings, sheet metal cutting, sanitary, garments&leather, glasses,jewelry and so on...
With the superfine laser products, price and services,our company is expanding to international markets. Our company’s slogan is simple:to sell our machines at the most competitive price to our worldwide customers, and provided 24hour well-responsed services after sale. Always higher quality is our forever goal.
- Place of Origin: Zhejiang, China
- Brand Name: TiHi
- Model Number: W309
- :
- :
- :
- :
- :
- :
- :
- :
- :
- :
Technical Parameter of W309 | |
Model No.: | W309 |
Laser Power: | 200W 500W 800W |
Laser Wavelength: | 1064nm |
Beam Range: | 0.3-3mm |
Pulse Width: | 0.1-20ms |
Pulse Frequency: | 1-100HZ |
Position System: | Red point/CCD |
Working table CNC system: | PLC/PC |
Working table scale: | 200*200mm--300mm*600mm(Optional) |
Position Precision: | 0.05mm |
Repeated Location Accuracy: | ±0.02mm |
Cooling: | Water Cooling |
Working table Bearing Weight: | 50Kgs |
Power Comsuption: | 4KW 8KW 12KW |
Net Weight: | 300Kgs |
Size Measurement: | 135*70*160cm |
Working Temperature: | 10℃-35℃ |
